PRO-LINK32-K1 32-Channel USB HD Audio Platform
10-in/10-out, 192kHz, low-latency USB audio interface evaluation platform for professional recording and production.
Product Overview
The PRO-LINK32-K1 is a professional USB audio interface evaluation platform from Pawpaw Technology, supporting 10-in/10-out channels at 192kHz high sample rate. The platform uses USB Audio Class 2.0 asynchronous transfer protocol, delivering precise, low-jitter audio streams.
Key Features
Multi-Channel 192 kHz Recording & Playback
Simultaneously capture or monitor up to 10 audio streams at 24-bit/192kHz, delivering pristine audio detail — ideal for band recording, surround mixing, and immersive content production.
Flexible Digital & Analog I/O
Seamlessly integrates MIDI, S/PDIF, I²S/TDM-8, and dual headphone amplifiers, allowing manufacturers to develop products ranging from entry-level to flagship without redesigning firmware.
Ultra-Low System Latency
Achieves less than 4ms round-trip latency with Windows ASIO drivers, ensuring smooth real-time monitoring experience.
Broad Compatibility
Compatible with Windows, macOS, Linux, and Android. Plug-and-play on macOS/Linux with no driver installation required.
Application Scenarios
- Professional Recording Studio
- Home Recording Studio
- Live Streaming
- Podcast Production
- Film/TV Dubbing & ADR
- Instrument Sampling
Technical Specifications
Sample Rate
48kHz/96kHz/192kHz
Bit Depth
24bit/32bit
Channels
10-in/10-out
Audio Protocol
USB Audio Class 2.0
Interface
USB-C
Digital I/O
S/PDIF, I²S/TDM
MIDI
Supported
Compatible Systems
Windows (ASIO) / macOS / Linux
Latency
< 4ms (ASIO)
Gallery
Ready to Upgrade Your Audio?
Experience professional sound quality with the PRO-LINK32-K1
